Monday, December 22, 2014

First Impressions: AF NIKKOR 35mm f/2.0 D

I’ve been weighing in on the AF NIKKOR 35mm f/2.0 D for nearly as long as the 50mm f/1.8 D. It’s only a tiny bit longer than the 50, but it’s built is a little more robustly. It has more in common with the other D lenses, except that it lacks a bayonet hood mount. Thus I bought it with the Vello equivalent of the Nikon HN-3.

I was surprised to see it shipping with the latest version of the rear lens cap, and no US prefix in the serial number despite its being an official US warranty model. So, this truly is the most up-to-date iteration of this long-lived lens.

In the hand it feels solid, and the manual focus is like silk. No play (and no viscous damping) in the direct coupled focus ring, unlike the geared G lenses which are difficult to focus manually due to gear lash. Sure, their clutched coupling allows you to adjust focus while you still have the shutter button depressed halfway. But by the time you rock the focus ring back and forth, you’ve missed the shot. G lenses are great, but more evolutionary than revolutionary, and not necessarily a replacement for their ancestors.

The hood is great, comparable to the real HN-3 in terms of quality. But ironically, the narrower Kalt 52mm metal hood I purchased for the AF 50/1.8 works fine too, even with a filter.

Having followed the great reviews and coming to fully appreciate the versatility of an autofocus 35mm lens that’s so small, light and fast has made this purchase a no-brainer. Especially now that I’m shooting full frame.

I’m fairly sure this will be my new Go-to AF lens.



Friday, December 19, 2014

It’s Like Buying a New Lens

How cool is it that I can still buy a brand new HB-18 hood for my AF 28-105mm f/3.5-4.5 D? Pretty cool. Back in the day, these were accessories. Today, the G lenses all come with hoods, undoubted subsidized by the cost savings of not having to include an aperture ring.

The hood is circular, so no problems given that the filter threads rotate on zoom. But, it’s also large enough to mount a 77mm filter with a step-up ring. And that’s pretty awesome now that I’m converting over to 77mm filters.

First Impressions: AF 50mm f/1.8 D

Finally, FINALLY! It’s been five years, and I’ve finally scored one of the best values in NIKKOR lenses.

I’ve been pining over this since I first started on my DSLR journey in 2010. There was no point in buying this since I already had the AF-S NIKKOR 50mm f/1.4. But now, with the full-frame D610, it makes sense. It’s the smallest, lightest, autofocus 50mm lens, with a direct-coupled, windowless focus ring, and an aperture ring which allows for macro lens reversal.

It took me a while to get used to its silver markings; I had forgotten that at some point Nikon had switched over to silver from the more traditional white. This is not the same caliber as the other D lenses, like the 20mm D, which has some heft. By contrast, this is light as a feather, and that's a bit disconcerting at first. It feels like it would be right at home on a Holga. But one turn of its direct-coupled focus ring, and it grows on you quickly. With only a filter thread for mounting a hood, it harkens back to the more traditional MF 50mm lenses. But its silver markings give a nod to the now. It’s in a class of its own, and a world apart from the AF-S 50mm f/1.4 G.



Thursday, December 18, 2014

Kalt 52mm Metal Lens Hood

As my new AF NIKKOR 50mm f/1.8 D does not have a dedicated bayonet hood, I decided to order this very inexpensive metal hood from Kalt.

My last experience with this brand was many years ago, when I purchased 35mm film canisters from them. I still use them to this day. It’s a well-established brand for generic accessories. I figured, for $9.95 I could’t go wrong.

Well, I was pleasantly surprised to find that this hood is just terrific. Extremely well-machined from aluminum, black anodized, and carrying a simple silver tampo marking: 52mm. Is it flocked inside you ask?. No, even better; machined ribs, and 58mm filter threads at the open end. But most importantly, I can fit the original lens cap inside. Or, I can just add a 58mm cap to the end.

If fits the 50mm AF-D perfectly, and is in fact, smaller in diameter than the lens itself, making it quite compact.

And, at 52mm, it also works perfectly with my Nikon 50mm f/1.8 E, Voigtländer Ultron 40mm f/2.0 SL II and even my AF-S DX 35mm f/1.8 G when used in DX crop mode.

Tuesday, November 11, 2014

ECSR

It stands for, “Every Camera Shoots Raw”. They do, it’s just that not all of them allow you to save the raw information. Even my Nikon D50 does, which is awesome since it tops out at a clean ISO1600, which means I can fudge ISO 6400.

Lately, I’ve been shooting solely in Raw on my D610. But I can’t help but feel it’s taking the easy way out. It’s forcing me to think less, which I don’t like. I don’t think Raw is necessarily a replacement for JPEG. Especially now that I can shoot HDR JPEG. Same goes for shooting in color and converting to B/W. I think there’s value in setting up a color space and working, thinking within it. It’s not unlike choosing a film emulsion, getting used to working with it, and accepting and taking responsibility for the results.

This makes me want to set up my U1 and U2 banks with settings that let me do just that. I’m wondering what results I would get if I used HDR to shoot in Black and White while dialing up the contrast.

Hmm.

Saturday, November 1, 2014

My Camera Goes “Zing”

Rainy museum day today, and the perfect opportunity to test out my new Zing camera wrap. And since I bought it for use primarily with the AF-S 50mm f/1.4 G, it gives me a chance to give that a workout too.

Like every lens I’ve purchased since owning the Nikon D90, I’ve considered how the lens will work with full frame. The 50mm f/1.4 G made it into the stable because it makes such a great portrait lens on APS-C cameras, and eventually the day would come when it would become an essential part of my full-frame kit. And that time is now.

At half the price, had the newer 50mm f/1.8 G been available I’d have bought it over the 1.4. Which is exactly why Nikon waited until they did to release the 1.8. But that’s just fine, because it puts the AF 50mm 1.8 D on my radar, a lens which is as close to perfect as you can get for about a C-Note.

To be honest, I haven’t used the 50 1.4 it that much; but I have a feeling the Zing-Equipped D610 will change all that.

The Zing is great when you just need something to protect your camera in transit, guarding against dust, moisture and bumps. After all, neoprene is used for wet suits, and this covers the camera so well, it’d take a lot for moisture or dust to get in.

I ordered mine in dark grey, which is reversible to black. It’s pretty easy to get off, but tricky to get back on. You sort of rotate the camera counter-clockwise, stuff it in lens first, and twist it into place, stretching the right side up. Then you wrap the flap around the front, and over the lens. The longer the lens, the more you have to stretch it, so normal lenses like the 50mm work great, and standard zooms are a little more challenging. For tele-zooms, they make a larger model.

Once on, it turns the camera into a nondescript grey blob, loosely resembling an SLR. Sort of like a sculpture. A second skin, close to the dimensions of the camera iteself. With lenses shorter than about 2", a bulbous pouch forms at the front, void of lens but offering additional protection nonetheless. It even works with the pancake-sized Voigtländer Ultron 40mm f/2. So, combined with a compact prime lens, this makes for a great street-cam setup.

It’s about as close to the traditional SLR half-case of the 70’s as you can get. With a modern twist.






Wednesday, September 17, 2014

More Fujifilm Woes

Just as I was about to publish my review of the Fujifilm X20, I discovered that like the X10 before it, it’s defective. One morning, I turned I attempted to take a photo in my way to work, and noticed that the OVF was actually flickering. And then I noticed the absence of the shooting data along the bottom. Oh, it was there; it’s just that the numbers and symbols had been reduced to outlines, and were practically invisible. I searched the topic, and encountered another person who had exactly the same problem in March of 2013, and then a other in July, intermittently.

I can see no explanation for this. The camera was stored and handled meticulously. I’ve tried resetting everything, and even pulling the battery (but only for a couple of hours). I’ve since pulled the battery and will let it sit for an extended period. But, I am anticipating the day when I will have to take it in to Fuji for repair.

At this point, my faith in Fujifilm as a manufacturer of cameras is waning. A lot. The whole X10 episode was inexcusable; to release a camera with defective sensor is simply inexcusable. How could it ever have passed QA by a company concerned with image quality; a company with a strong desire to be one of “The Big Three”.

Not including the two Fujis, I have a total of six digital cameras, which have never failed. That includes my Nikon D50, which was purchased used. This definitely does not bode well for Fujifilm. I gave them a second chance with the X20, and this is how I was repaid.

So, before I finalize my X20 review, I’m going to see how this all pans out, including the service experience, should that be necessary.







Tuesday, August 26, 2014

The Fujifilm X30

Leaked: The Fujifilm X30
Only days after receiving my X20, I went looking for more info on the X30 and came upon this…

There’s no question, it’s a good looking camera. A little more modern that the X20, but still has that retro-ish feel. Except for one important fact: NO VIEWFINDER!

At least no optical viewfinder, and a groundbreaking one at that for a “rangefinder”. One that has color-coded shooting information right in the finder. After reading the first impressions review on dpreview, I can say without hesitation that I made the right decision to get the last of a dying breed, and save $100.00 at that. (Not that I would have paid the full retail price of $599.99 for the X30, but still.)

The X30 holds no appeal for me over the X20, and I much prefer the X20 over the X10; They actually got it right except for one thing; they shortened the maximum Image Preview from 3.0 seconds to 1.5 seconds. Why? A typical example of throwing usability completely out of the window and getting it blatantly wrong. The 1.5 second timing is so fast, that at first I thought the image preview was not working. The other major error was removing the option to turn the LCD off altogether from the display button and putting it in a dedicated menu item along with eye sensor, OVF and LCD. All of these options should be part of the display button. This is what happens when you don’t do usability testing on cameras which have user interfaces.

Still, I am overjoyed with this camera. Overall, the menus have improved by being more Nikon-like in their overall function and appearance, and the Q-button is simply genius. I can’t wait to take this out shooting.

But, in defense of the X30, many are criticizing it for not having a 1" sensor. But forgive them, for they just don’t understand the physics of optics. In this camera, sensor size, speed, and focal length range are all in perfect, critical balance; increase the sensor size, and the others must change as well, and not for the better.

And now for the harsh from me; my faith in Fujiflm as a member of the elite three has waned. I’m happy to own this camera, but I don’t think I would invest in a more expensive offering from them. They just don’t seem to have the experience needed to make a near-flawless high-end camera, which I already have in the Nikon D610.


Sunday, August 24, 2014

First Impressions: Fujifilm X20

Faux Pas; All camera manufacturers have them. A recent one for Fujfilm was the X10. A great camera with one major flaw; a defectively designed sensor.

Review: Voigtländer Color Skopar 20mm f/3.5 SL II

Voigtländer Color Skopar 20mm f/3.5 SL II

There’s just something about “pancake lenses” that many find appealing, and each company has traditionally offered one or two. But Nikon’s offering (the NIKKOR 45mm f/2.8 P) is a lens for collectors and not for shooters. It just falls short in performance at the borders and edges. The logical option to this lens is the Voigtländer Ultron 40mm f/2.0 SL II. It’s fast, sharp and even a bit wider; perfect for full-frame, but still very usable on DX.

That said, Voigtländer (one of two brands by Cosina, the other being…Zeiss!) continues their expertise in pancake lenses with this lens, the Color Skopar 20mm f/3.5 SL II. A bit longer and slower than the Ultron, it fills the gap where a manual-focus DX street lens should be, and though not as fast as Nikon’s considerably larger AF NIKKOR 20mm f/2.8, it’s considerably sharper at the borders making it ideal for single-shot panoramas.

The sample pictured is the previous version with a rubber focus ring grip. The latest iteration has a fluted all-metal focus ring, very traditional in appearance. If you’re an SLR shooter, but like the idea of a rangefinder, this gets you a little closer to that experience. Beautifully crafted of black-anodized aluminum, it’s light and has a compactness factor of 19, compared with 15 for the Ultron and 7 for the 45mm NIKKOR P.

What’s Missing Infrared focus index.

What’s Included
Front and rear lens caps.


Aperture Ring Yes. Smooth with positive full-stop clicks, except for f/4; hard stop at f/3.5 instead.

Auto Focus No.

Bokeh Not yet evaluated.


Close Focus 8 inches (0.2m).

Color Rendition Excellent.


Compactness 19 on a scale of 1-500, factoring in diameter, length and weight.

Compatibility Nikon F-Mount with CPU. Works flawlessly on any Nikon body since 1977, and meters on cameras without an aperture sensing tab. Does not seem as sharp on other cameras such as Canon using adapters, even if non-optical.

Construction 9 multi-coated elements in 6 groups with one aspherical element. Metal mount, body,
aperture ring, focus ring, inner barrel and filter threads.

Country of Origin Japan.

Coverage 135 film, FX and DX.

Diaphragm 9 curved blades.

Distortion Moderate, about 1.9% of complex distortion.

DX Performance On an APS-C body, this lens would be 30mm at f/3.5 with a 71° field of view; good for street photograph in good light.


EXIF Encoding Yes.

Extension Tubes Works fine with both manual and auto extension tubes, but there are better options.

Falloff Gone by f/8, which is where this lens shines.

Filter Thread Metal, 52mm. Does not rotate.

Ghosts and Flare Minimal.


Hood Optional LH-20 metal hood. Does not work with the domed metal hood that comes with the Voigtländer Ultron 40mm f/2.0 SL II

Included Standard side-pinch front lens cap, rear cap.

Lateral Color Fringes Not yet evaluated.

Macro Not the best choice for macro, but unmount it from the camera body, preset the aperture, flip it around and hold the filter threads squarely against the mount, and you can get some incredible macro shots bordering on photomicrography.

Manual Focus
Focus ring is silky smooth and well-damped with a hard stop at infinity. Has a very usable depth-of-field scale, but no infrared index.

Maximum Reproduction Ratio Not yet evaluated.

Optional Accessories LH-20 metal hood.

RoHS Compliance Not specified on lens. When the chip dies, this will still function perfectly as a manual focus lens.


Sharpness Super sharp at all apertures. Some coma and falloff at f/1.8, gone by f/2.8. Better performance wide open that the f/1.4.


Size 2.5"dia. x 1.1" (63.7mm x 28.6mm)

Spherochromatism Not yet evaluated.

Sunstars At smaller apertures, makes soft 18 point sunstars..

Teleconverters Not yet evaluated.

Variable Aperture Range
 None; constant aperture.

Versatility A great lens for panoramic images on FX; Works well for street photography on DX.


Vibration Reduction (VR) None. Use speeds as low as 1/30 s, or use “burst” mode to take several exposures and choose the sharpest.


Vignetting Shoot wide open to f/5.6 for a vignetting effect, which is gone by f/8.

Weight Approximately 7.0 oz (199.5g).


Build Quality ★★★★
Optical Quality ★★★★
Value ★★★★

The Bottom Line So thrilled was I with my Voigtländer Ultron 40mm f/2.0, That I decided to get this as a companion, especially since at the time I was craving a good 30mm street lens for my Nikon D90. On a the D610 however, it finds new life as sharp, compact ultrawide, which has very distinct advantages.


It’s a little trickier to work with than the Ultron, but the rewards are worth the effort once you get the hang of it. Focusing at infinity is challenging, because at infinity, the borders are actually sharper than the center! you just have to set the lens at the hard stop, and have faith. As with any ultra-wide lens, the depth of field is amazing, and even at f/5.6, it ranges from 10' to infinity at that hard stop. So, No worries. Set the focus at 8' to f/8 on the hyperfocal scale, and enjoy sharp focus from about three feet to infinity. Pretty much makes AF and VR unnecessary.

If you’re planning on using any sort of lens shade (always a challenge with any ultra-wide) it seems that  foregoing a filter is the way to go. The 52mm Vello Snap-On Tulip Lens Shade sans filter is probably the most compact option, and the vignetting is practically invisible. But the minute you extend outward with more than one filter, it’s all over. The other path I’d recommend is a 52-77mm step-up ring with the 72mm Vello Snap-On Tulip Lens Shade, which will work well with other setups. But this is really clumsy, and best for critical tripod work. Voigtländer makes a dedicated aluminum shade for this lens (LH-20), but at $45.00, there are much better options, including none since it has very good flare resistance.

So, this lens make much more sense on a full-frame DSLR, and yields some pretty nice single-shot panoramas. Cropping off the corners improves the performance a bit, while sharpness is consistent edge to edge. It’s my go-to lens for this kind of work.




Sample Images (FX)
NYC from Hoboken, AM. Shot into the sun with virtually no ghosts and flare.

Jersey City, PM. Vertical composition, corrected for perspective distortion.
NYC from Jersey City, PM. Single-shot panorama.


Sample Images (DX)
Monhegan Island

Coastal Maine Botanical Gardens, Boothbay

Coastal Maine Botanical Gardens, Boothbay

Coastal Maine Botanical Gardens, Boothbay

Coastal Maine Botanical Gardens, Boothbay

Coastal Maine Botanical Gardens, Boothbay

Coastal Maine Botanical Gardens, Boothbay

Monhegan Island, Maine


Monday, August 4, 2014

A Mirrorless for Me

On my way to Home Depot, I stopped in to Best Buy to see if they had a Zing Camera Cover. But I found something even more interesting...

I did a double-take as I passed the Sony display featuring the A7 and the Alpha a6000, and I just couldn’t resist. The thing I was most curious about was the viewfinder. Just how close to “real” could a 2.4MP EVF be? Well, I’m still not crazy about them, but I could definitely live with this camera.

The resolution was fine, the refresh rate adequate. But what was working in its favor for me was the sheer amount of info. Once I figured out how to access Manual Focus (I had to use the C2 button), the viewfinder accommodated me by enlarging the view as soon as I rotated the focus ring. These days, when things actually do what they’re supposed to do, I’m impressed, especially when it comes to cameras. But in addition to this little epiphany, there were all kinds of other information that made the EVF worth the price of a “synthetic” image.

Handling-wise, the camera was light, and felt pretty good in the hand, despite the small size and fairly hefty 28-70mm f/3.5-5.6 lens. These OSS lenses are about the same diameter as a traditional 135 manual focus lens, but seem to be overly long. To use Minolta AF lenses, the LA-EA4 adapter is required, which adds additional weight and bulk. Good luck figuring out which lenses work with which camera, as the mount is EF, but who knows if the lenses will cover a full frame or not. This guesswork is avoided with the Nikon system. All the DX and FX lenses work with with either camera body one way or another.

The build quality was excellent, with a metal body (magnesium, not brass) and a gloss-black enameled finish, not quite up to the traditional 70’s spec, but as good as we can expect for the current state of the art. As far as I’m concerned, If this is the direction mirrorless cameras are headed, the future is bright. But, the jury’s still out, because Sony, ironically, is the leader in this respect. These are the cameras Nikon and Canon should be making. But instead, they’re focusing on the 1" sensor, which incidentally, so is Sony. Had I not chosen the AE-1 over the XG-7 back in the 70’s, this camera might have been a foregone conclusion.

I was also quite impressed with the Alpha a6000 which was right next to the A7. While the A7 harkens back to the Olympus SLRs of the 70’s, the a6000 evokes memories of the equally significant rangefinder. Equipped with an APS-C sensor, this camera is more than adequate, although the focus-by-wire approach, which is just plain silly, does not do it justice as does the A7’s more traditional approach.

The multi-purpose command dial could have been a dedicated exposure compensation dial, aligning it more closely to the A7, but alas, no. Still, it’s miles ahead of it’s predecessors.

These cameras leave me hopeful that when the time comes to retire the DSLR (which is inevitable, I’m afraid) the viewfinders will be up to snuff.






Saturday, July 26, 2014

Untermyer Park, Revisited

Literally. This was my second visit to this historic site, and an opportunity to practice what I preach.

Accompanied by my honey, I wanted to travel light. She had an opportunity to put her AF-S Zoom-NIKKOR 18-200mm through its paces on her D3100, and I my Voigtländer Ultron 40mm f/2.0 SL II on the D610.

I have to say, on a full-frame camera, 40mm is amazingly versatile. In tight spaces, I had no problems with cropping out important elements, and it always seemed to give me the ideal angle of view. Getting in close was not an issue either, and I had the dedicated 39mm close-up lens with me just in case.

Focusing was amazing. Very quick and easy with the D610’s three-segment indicator, and no matter how I was holding the camera, I could focus with whichever fingertip I had available. I never missed autofocus.

What I did miss was my trusty Hoya HRT polarizer; don’t have one in 52mm, and didn’t want to bulk up with a step-up ring. With a fast 2.0 aperture, it would have worked great.

I’ve yet to order the dedicated Nikon CF-DC5 case, but with this lens I’m thinking a Zing camera cover might be a more compact solution. I can definitely see myself toting this setup around often.




Sunday, July 13, 2014

Day One: Wellfleet, P-Town

Traveling light with the Voigtländer Ultron 40mm. Will be great to use this at it’s native 40mm, instead of the usual 60mm. Also looking forward to seeing the 3-segment focus confirmation at work.


Monday, June 2, 2014

Review: Nikon 50mm f/1.8 Series E

Nikon 50mm f/1.8 Series E (Late). Pancake or no?
This lens was part of a series of lenses which were designed for the launch of the Nikon EM in 1979, and subsequent FG and FG20. These were extremely compact SLRs for their time, and a surprise marketing move on Nikon’s part. And so was the introduction of these lenses, which were not particularly well-received. They did not carry the NIKKOR designation, and incorporated a lot of plastic to save weight and cost. But, their optical and build quality was outstanding nonetheless.

Nikon 50mm f/1.8 Series E (Early)
Then in 1981, in response to complaints by Nikon users, they cosmetically upgraded this lens (along with other E-Series lenses) to look more like their NIKKOR offerings. The plastic “windowed” focus ring was replaced with a traditional metal one with an AI-S style grip. The “body” reverted to the silver grab ring, although this was most likely aluminum instead of dull-chromed brass. But the optical design and quality all stayed the same. The upgraded version is a tiny bit longer than the original, which is so small that it is often referred to as a pancake lens.

The optical formulae used in these lenses were simple; ones that could produce excellent quality at reasonable cost. By today’s standard, the build quality is outstanding, and the image quality among some of the best lenses out there. This design uses only single coated elements, and still it has minimal ghosts and flare due to it’s simple optical design (the current design uses seven multicoated elements in 6 groups, including one aspherical element.)

This lens enjoyed a six-year life span, and was discontinued in 1985.

What’s Missing Nothing. This lens has all the features and quality you’d expect in a normal lens.

What’s Included
Compactness and value. If you’re itching to go the traditional, manual-focus route, this is a great way to get started. Oh, and front and rear lens caps.


Aperture Ring Yes. Smooth with positive full-stop clicks.

Auto Focus No.

Bokeh Somewhat agitated, which is to be expected in an uncommonly sharp lens.


Close Focus Two feet (0.6m).

Color Rendition Excellent.

Compatibility Nikon F-Mount. Works flawlessly on any Nikon body since 1977. Due to their longer flange focal distance, Nikon F-Mount lenses work beautifully on Canon bodies with non-optical adapters

Construction 6 single-coated elements in 5 groups. Metal mount, body, focus ring, inner barrel and filter threads. Plastic aperture ring.

Country of Origin Japan.

Coverage 135 film, FX and DX.

Diaphragm 7 curved blades.

Distortion None.

DX Performance On an APS-C body, this lens would be 75mm at f/1.8; one really fast and compact portrait lens.


EXIF Encoding None.

Extension Tubes Works great with both manual and auto extension tubes.

Falloff Not yet evaluated.

Filter Thread Metal, 52mm. Does not rotate.

Ghosts and Flare Minimal.


Hood Nikon HR-4 Folding Rubber Hood. Works well with the domed metal hood that comes with the Voigtländer Ultron 40mm f/2.0 SL II

Included Standard side-pinch front lens cap, rear cap.

Lateral Color Fringes Not yet evaluated.

Macro Works great as a macro lens with extension tubes. Can easily be reversed for even higher power magnification due to its 52mm filter thread which is compatible with the Nikon BR-2A macro reversing ring, and it’s mechanical aperture, which can be set with the lens unmounted. Works well with the closeup lens that comes with the Voigtländer Ultron 40mm f/2 SL II.

Manual Focus
Focus ring is silky smooth and well-damped with a hard stop at infinity. Has color-coded focus and depth-of-field scale and infrared index.

Maximum Reproduction Ratio Not yet evaluated.

Optional Accessories None.

RoHS Compliance N/A; all-mechanical construction.

Sharpness Super sharp at all apertures. Some coma and falloff at f/1.8, gone by f/2.8. Better performance wide open that the f/1.4.


Size 2.5"dia. x 1.3" (63.3mm x 33mm)

Spherochromatism Not yet evaluated.

Sunstars At smaller apertures, makes soft 14 point sunstars..

Teleconverters Works great with both 1.4x (70mm f/2.5) and 2.0x (100mm f/3.5) teleconverters.

Variable Aperture Range
 None; constant aperture.

Versatility A compact, super-sharp normal lens which is easily adapted for macro and telephoto photography. Very good for portraiture.


Vibration Reduction (VR) None. Use “burst” mode to take several exposures and choose the sharpest.


Vignetting Slight falloff at f/1.8, gone by f/2.8.

Weight Approximately 4.75 oz (135g).


Build Quality ★★★★
Optical Quality ★★★★
Value ★★★★★

The Bottom Line When I first learned about the E-Series lenses and the story behind them, I was intrigued. And since I planned to get a manual focus normal lens anyway, I let KEH make the decision for me. It was between this or the 50mm f/1.8 AI-S; whichever was available in EX+ condition or better I would buy.


I had originally hoped that I would receive the early version of this lens, with the plastic focus ring, but looking back, I’m glad this is the one I received. It’s all metal and one solid piece of glass. It’s essentially exactly the same as the NIKKOR 50mm f/1.8 AI-S, only in a smaller, lighter package.

On my new D610, this lens is simply marvelous. A great walk around lens, and so fast and sharp that it performs nicely as a 100mm f/3.5 telephoto lens with a 2x teleconverter attached. I often pack just this lens along with my teleconverters and extension tubes for a very versatile kit.

Without autofocus motors, VR electronics and lead-free solder, E-Series lenses will never let you down, and are a good investment as well as means to great images.




Sample Images

Makes soft, 14 point sunstars.
When the sun in not in the shot, but close to the border, flare and ghosts become apparent.

…but when the sun is further away from the borders, flare and ghost are well controlled. A lens shade can definitely be  beneficial, but is not necessary in most cases.
The color is simply amazing. The lens is super-sharp, so a less-than-perfect bokeh is to be expected. Still, due its curved, seven-blade diaphragm design, it holds up pretty well.


Sunday, May 25, 2014

Freelensing with Minolta and Olympus Lenses

Although there are both optical and macro lens mount adapters available to mount Olympus and Minolta lenses to Nikon bodies, they all add about 10mm of extension to the optical path. Great for extreme closeups in the case of the macro-type adapter, but for wider shots you need to get closer. Freelensing is an easy and inexpensive way to achieve that, and offers some creative effects as well.

Tuesday, May 13, 2014

Pinhole a la D610

Nikon D610 + Lensbaby Pinhole/Zone Plate Optic
1/60 @ f/177, -0.67, ISO 6400

Friday, May 2, 2014

Nikon Capture NX-D on the Way

I never really considered the D610 for infrared, despite its higher ISO which makes it two stops faster than my D90 (Three really, but I think 25,600 is pushing it.) it’s not the long exposure time that bothers me, it’s the white balance issue.

Back when I was experimenting with the D90, I had read somewhere that since you can’t set the white balance, you should just shoot raw and set it afterwards. But despite Camera Raw’s ability to go all the way down to 2000°K, it just couldn’t cut it. Then the D50 came along.

I was amazed at how easy it was to set a custom white balance for IR on the D50, and when I did the JPEGs came out fantastic. But again, I could do nothing with the NEFs.

Then, not too long ago I had read somewhere that with Nikon’s Capture NX software, you could set it lower. This software was not a priority for me, since between Photoshop/Camera Raw and Apple Aperture 3, I had things pretty much covered. And, being a usability analyst, it pained me to think of just what the Nikon experience would be like. But, if I could just get that white balance lower, It’d be worth it. So, I put it on the back burner.

Today I decided to price out a copy, and discovered that the latest version is in beta, and available as a free download. Try before you buy. So I went for it.

As predicted, I wasn’t blown away by the interface. I didn’t crack open the downloaded PDF manual. Again, as a usability analyst, if I can’t figure how to use an app’s core functions in 10 minutes it’s an automatic fail. But, it wasn’t all that bad. Turns out I couldn’t adjust the white balance low enough with the slider. But what I could do is use the WB eyedropper tool on the bluish-colored foliage, and the color snapped into place. And, the temperature and tint sliders were still in the middle and could be adjusted further. And oh what a range of adjustment. I was able to restore some of the original color to the image, or so it seemed. Even the exposure range was vast. A severely underexposed image opened right up, possibly aided by the extra bit depth on the D610.

But what’s really exciting is that I’ll be able to shoot RAW on the D50 and actually use the images. The JPEGs come out great, but finally being to work with the NEFs will be a real treat.

First Impressions
The file interface is much like Adobe Bridge, in that you browse your folders; you do not have to import images into a separate library. Unfortunately, it’s not quite as elegant. But all the tools are right at your fingertips; you don’t have to “open” an image to modify it.

It seems to have borrowed from Aperture in that once you use an adjustment tool, it’s added to the panel on the right, which scrolls as needed. You can close it at any time though, and the effect remains in place. You can turn effects on and off, and of course, save different versions. All these are now stored in a sidecar file, just like Camera Raw.

Filtering is very clumsy. It has to do a build each time, instead of working in real time like bridge. Compare images does not seem to work.

It’s very buggy, It has hung twice, and I’ve had to do a force quit to get it running again. But after all, this is Beta software and taking that into consideration, thing weren’t too bad

Nikon Capture NX-2 is quite reasonable at $139.00. I’m on the fence as to whether or not to buy it to see how it works, then upgrade to NX-D. This way, I’d have both versions, if they don’t disable the previous version so you can’t run them both on the same workstation.


Thursday, May 1, 2014

Review: Nikon D610 Full-frame DSLR

The Nikon D610
“Entry Level” full-frame DSLR, with professional features and performance.

The Nikon D610 (minor upgrade to the cursed D600) is my third DSLR, and my first experience with full-frame digital photography. Up until now, I’ve been shooting APS-C, but preparing for the inevitability of moving to full-frame photography by purchasing mostly non-DX lenses.

Moving to full-frame from APS-C is all about the subtleties associated with working at a shorter focal length. The reduced depth of field, the decreased magnification, the reduced effects of diffraction. But moving to the D610 is also about moving to the next generation of DSLR over it predecessors; for me, those are the Nikon D90 and Nikon D50. While both are very capable cameras, their layout of controls is not optimum for a photographer who was weened on the film SLRs of the 70’s.

If you’re like me, and enjoy casual shooting one moment and hunkering down for some serious photography the next, the D610 is for you, because it has the perfect combination of professional features and automation.

The D610 has a feature set which includes those important but perhaps not essential functions missing from the D90, and not even under consideration in the D50

What’s included
  • Mirror lock-up for vibration-free exposures
  • Non-CPU (Manual Focus) lens metering capability (A and M Modes)
  • Restoration of aperture ring functionality on CPU lenses
  • Built-in timer for interval or time-lapse photography
  • Metering pattern indicator in the viewfinder
  • Artificial Horizon
  • AF Sensors now work with lens/teleconverter combos up to f/8.0
  • Quiet shutter mode, single or 3FPS
  • Wall-plug/cord option on charger
  • Built-in flash now support repeating flash and modeling flash.
What’s missing
  • 5:4 crop mode, but you can crop in camera with the trim function
  • PC (Pronto-Compur) flash terminal, but you can use a hot shoe adapter
  • AF-ON button, but you can program the AF-E/AF-L button to perform this function


Bracketing No changes here. Still 3 frames, still up to 3 stops differential. Button still located on the left below the flash button, where it should be.

Construction Professional-grade magnesium alloy body, with weather sealing. Not as robust as the professional D800, but well-built nonetheless. Traditional strap lugs.

Controls More dedicated and better placed controls make this camera a pleasure to use, even for those accustomed to a previous layouts. All the shutter-release related functions are now on a dial concentric with the Mode Selector. The AF button has been placed in the center of the AF/MF lever, which is a much more logical grouping. The Picture Control setting now has its own dedicated button, so no more diving into menus for this essential function. You can even set the camera to use the aperture ring instead of the command dial on CPU lenses (Non-CPU lenses must use this feature).

Country of Origin Thailand.

Dual SD Cards This feature brings the D610 one step closer to being a professional camera. But the real payoff is never having to worry about not having a card in your camera after you’ve offloaded images. Ironically, the “Professional” D800 has two slots also, but one is Compact Flash; that gives the impression that this is still a “transitional” camera. The days of CF cards are limited, even for professional applications. Controls in which the + and - are reversed (according to usability best practices) have finally been corrected.

Exposure If there is a lot of black in your images, the meter tends to overexpose. Use an exposure compensation of about -0.7, and you should be fine. Digital photography favors underexposure, so it’s always a good idea to shoot a little on the low side, and open up afterwards. I aways shoot at -0.3 regardless.

Finder With 100% coverage in FX and 97% in DX, this camera finally feels like a real SLR. Compared with the professional F3, the experience (except for the comprehensive finder information display) is the same. Also features a glass pentaprism with a 0.7X magnification (50mm lens) and has a 21mm eye point.

Flash Built-in flash now includes repeating mode for strobe effects and modeling flash. Both built-in and external flash tends to overexpose, so use use it with -0.7 exposure compensation and you’ll be fine.

Fn Buttons Two of them, one dedicated and the other via the reprogramming of the DOF Preview button. I usually keep the DOF, but switch up the dedicated button as needed, which is easy to do using the menu launched by two presses of the Info button. I tend toward using it to access “My Menu” which lets me call up my customized menu immediately. I also often set it to Spot Metering, as it’s so easy to use my pinky to temporarily jump into this mode to take spot readings.

HDR (High Dyanamic Range) A simple and elegant way of extending the dynamic range of photography in a single step, and a must-have for today’s cameras. Nikon has chosen to implement it only for JPEG images, which eliminates the redundancy of combining it with RAW, which already gives you the means to optimize dynamic range at your disposal. With three levels of effectiveness plus auto, It is well-implemented and designed for hand-held use in any of the PSAM modes. It’s not available in full auto mode, but you can use RAW or RAW+JPEG. Also, you can’t crop HDR images in the camera using the trim feature.

Image Area Selection You now have have a choice of two image areas, FX (full-frame) and DX (APS-C), or you can set the camera to switch automatically to DX when you have a DX lens mounted. At the DX setting, the D610 produces wonderfully uncongested 10MP image files. With FX lenses, you can use the DX setting as a built-in 1.5x teleconverter. Some DX lenses such as the AF-S DX NIKKOR 35mm f/1.8 G can be used in FX mode and cropped slightly to produce the equivalent of a 40mm lens, or left as is for a Holga “Black Corner” effect.

ISO Finally, ISO is exactly where it should be, with a native range of 100-6400. But, you can also set it outside of this range as low as ISO 50 or as high as ISO 25,600. Honestly, this is as high as it needs to be, because you can actually use the images shot at ISO 25,600 due to its uncongested sensor. Nikon could have rated it at 51,200 or even 102,400, but the images wouldn’t have been as usable. Auto ISO performance remains the best in the industry.

Mode Dial The mode dial now has a central button to lock it into place to avoid accidental changes, just like my professional F3.

Non-CPU Lens Data The D610 behaves like a traditional SLR with respect to manual focus lenses. You can set the focal length and maximum aperture for up to nine lenses, and if you need to work with more it’s easy to fine-tune existing settings. Works will all lenses manufactured after 1977, and earlier lenses if they have been converted to AI. Works with uncoupled lenses of different makes (with adapters) through the use of stopped-down metering.

Release Button to Use Dial This little feature makes a huge difference in terms of usability. It allows you to change settings by simply pressing a control button once and not having to hold it down while you rotate the appropriate command dial. Once you’ve made the selection and engage either the same button, a different button or the shutter release, the setting is saved and you can take your shot. No more finger contortions to destabilize your grip. Especially helpful for dialing in an ISO to achieve a specific exposure without taking your eye off the viewfinder.

RoHS Compliance Not indicated

Scene Modes More scene modes are included than ever before, and individual scenes have been moved off the mode dial and now appear as menu selections, with thumbnail examples. The combination of these and the U1 and U2 modes was the deciding factor for me between the D610 and the D800. You can use these modes as needed to temporarily jump out of your currently set PASM modes when you need to without messing up your settings.

Shutter With a frame rate of 6 FPS, the D610 is now amongst the fastest cameras on the market, with a level of performance enjoyed by professionals. It also features a quiet mode in both single release and continuous modes at 3 FPS. Tested to 150,00 cycles, it has a flash sync speed of 1/200 s (1/250 in FP mode). The days of 1/500 flash sync are over since sensors became more dense than 10MP.

Size Slightly larger that the average APS-C DSLR, but not unwieldy.

Three-Stage Focus Confirmation Finally, a DSLR that plays well with manual focus lenses. The three-stage focus confirmation light makes manual focusing much easier, and you can train yourself to see it with your peripheral vision as you compose your shot. The focusing screen is very easy to replace, but I have not yet encountered a quality split prism / micro prism replacement that I would recommend. Manufactures of quality screens state that there are technical limitations on both the D600 and D800 models that make these screens impractical. I’ll keep you posted on that.

Trim Part of the retouch menu, two new trim settings have been added; 1:1 and 16:9. Along with the existing 3:2, 4:3 and 5:4 aspect ratios, this allows even more creative, in-camera processing, especially helpful when shooting with DX lenses in FX mode.

U1 and U2 Modes These allow you to recall everything from exposure to ISO and Autofocus settings, and are sadly missing from the D800.

Weight About 30 ounces (just slightly less that two pounds). Due to is slightly larger size, it seems almost lightweight, and with a pancake lens attached, you can carry it around comfortably all day.


Build Quality ★★★★
Optical Quality ★★★★★
Value ★★★★

I fought with myself for a long time between the purchase of this or the D800(E). The amount of usable features in this camera over the D800 eventually clinched it. I never particularly cared for Nikon’s implementation of mode selection in the pro bodies, and didn’t care to lose the automatic and scene modes I had come to appreciate even if I rarely use them. With image quality 90% of the D800 (and an actual edge in terms of ISO performance) the feature set, reduced size and weight, and the ability to use more of my existing accessories (such as my DR-6 right angle finder) it quickly became a no-brainer.

My original thinking was that the 36MP sensor of the D800 would produce awesome APS-C images in DX mode. But this was a poor justification for spending an extra $800.00, just to say I had a professional body and deal with truly enormous file sizes. I do enjoy shooting DX on the D610, and the 10MP images that it produces are outstanding. In fact, I no longer shoot at the “L” resolution in FX mode, as the 13MP images that the “M” resolution produces are more than enough for general photography. I use the L resolution as necessary depending upon the shooting circumstances, and always with DX lenses.

Compared to the Leica M Typ 240
I have a colleague who recently purchased a Leica M type 240. An independent test has revealed that the D610 with the AF 35mm f.2.0 D lens is actually sharper that the M typ 240 with the Leica Summicron-M 35mm f/2 ASPH. It also has considerably less noise. Both cameras use a 24MP full-frame sensor and top out at ISO 6400, although the D610 permits 2 additional stops to ISO 25,600. I rarely shoot beyond the “native” upper limit of ISO on any camera, and am in favor of the rather odd way in which Nikon implements extended ISO.

Other than the fact that one is an SLR and the other a Rangefinder, these two cameras are amazingly similar in terms of image quality. The Leica M’s chunky body is not exactly svelte, and the D610’s body is a reasonable size and weight for a full-frame DSLR. Used with a compact, moderately wide manual focus lens like the Voigtländer Ultron 40mm f/2.0 SL II, the experience is just as fulfilling to me as shooting with the Leica. This is not to say that the experience would be as fulfilling to those who enjoy people openly bowing to them for holding a Leica, whos status and retail value are exemplary. But hey, I just want to take pictures, and it’s good to know the D610 is in such good company.

Is this test valid? Who knows. Lenses vary from sample to sample and perhaps this was working in Nikon’s favor. But perhaps my colleague and I will put these two cameras head to head and see what we come up with.

The D600 incident was unfortunate and blown out of all proportion by fear, uncertainty and doubt. But the upside is that it produced this camera, which although only a slight improvement over the now infamous D600, is one outstanding way for the amateur photographers to enjoy the benefits of full-frame photography.

Highly recommended!


Review: AF Zoom-NIKKOR 28-105mm f/3.5-4.5 D

AF Zoom-NIKKOR 28-105mm f/3.5-4.5 D
Back in the day, this lens was an upgrade to the AF-Zoom NIKKOR 28-70 f/3.5-4.5 D, both of which provided superior optical quality. It was introduced in 1998 and was often bundled with the F100, making it a film-era lens. Discontinued in 2006, it enjoyed an eight-year life cycle, and it will be exactly sixteen years old come this september.

The beauty of this lens is its versatility, but when you combine that with its sharpness and low distortion you come up with a real winner. Its very useful range 3.75x zoom range of 28-105mm make it a lens you can keep on you camera at all times. It’s speed is a cut above average, topping out at f/4.5 instead of the usual f/5.6 at upper limit of its zoom range. This is good for photogs who want to take advantage of its other useful feature: Macro capability.

Modern lenses typically have a close focusing range under two feet at all zoom settings, and here the 28-105 D doesn’t disappoint. At 105mm, this allows you to get pretty darn close. But this lens has a macro “switch” which unlocks the focus ring and extends its travel, allowing you to focus as close as 8.4", at which point you can achieve a 1:2 reproduction ratio. This is the same as Nikon’s 55mm, 105mm and 200mm manual focus lenses! So, although it is 1-1/3 stop slower, this lens can essentially take the place of a macro lens in your outfit.

What’s Missing Two features that distinguish a macro lens from a standard lens (besides the reproduction ratio capability) are a long focus ring travel, and reproduction ratio markings on the focus scale. This lens has a rather short focus ring travel, although it is extended in macro mode (the reason for having the switch is to optimize travel for both scenarios) and no markings other than an orange line to denote the macro range.

What’s Included A direct-coupled focus ring, which has no “slop” when rocking back and forth to fine tune the focus. This is very import, as it differentiates this D lens from a G lens in which the outer focus ring is coupled to the inner barrel vs. a gearing system. This makes manual focusing on a G lens quite a challenge.

There’s a little trick to using this lens. If you use in macro mode with autofocus, and try to “retract” the lens barrel by zooming it all the way back to 28, it might stop at 50 requiring you return the macro switch to the normal mode. You can’t! That is, if the lens is still focused in the sub 0.5 meter range, the switch won’t slide to the normal position. And, since you can’t rotate the focus ring by hand in AF mode on any D lens, you have to either switch to MF mode, or simply autofocus on a distant object. You then simply flip the switch and zoom all the way back in. A small price to pay for such versatility.


Aperture Ring Yes. Works with both digital and manual focus film bodies.

Auto Focus Relatively slow. Mechanical focus linkage allows AF only with cameras equipped with a motor. Noise it about average for a D Lens.

Bokeh Not yet evaluated.

Close Focus 1.7 feet at all focal lengths (0.7 feet in Macro mode from 50mm to 105mm).

Color Rendition Not yet evaluated.

Compatibility Works with all Nikon digital cameras, but will not autofocus on D40, D60 D3000 and D5000 series bodies. Works with all autofocus and manual focus film bodies.

Construction 16 elements in 12 groups, including 1 hybrid aspherical element. Plastic outer barrel, metal inner barrel, metal mount; no rear gasket.

Country of Origin Japan.

Coverage 135 film, FX and DX.

Diaphragm 9 curved blades.

Distortion Much better than the average zoom, it’s negligible except at 28mm.

DX Performance When used on a DX camera this lens has a very usable range of 42-157.5mm, and is faster at the long end than the average lens it its class. It provide nearly a 1:1 reproduction ratio in macro mode. 42mm is the optimal “normal” focal length, while on a FX camera, 105mm is a typical focal length for macro lenses.

EXIF Encoding The focal length is accurately recorded at all zoom settings.

Extension Tubes Even with all three of the tubes from the Kenko Auto Extension Tube Set DG stacked, I was able to achieve autofocus. The addition of the tubes allows you to achieve greater than 1:1, but more importantly they increase your working distance at lesser magnifications.

Falloff Minimal; usually visible only at 28mm @ f/3.5. Never a problem on DX.

Filter Thread Plastic, 62mm. Rotates with zoom, but not focus.

Ghosts and Flares Reasonably good resistance when pointed directly into the sun.

Included Standard center-pinch front lens cap, LF-1 rear cap.

Lateral Color Fringes Not yet evaluated.

Macro Outstanding macro capability for a general-purpose lens. In macro mode, achieves a reproduction ration of 1:2, which can be extended to 1:1.3 (nearly 1:1!) simply by shooting in DX Crop Mode.

Manual Focus Focus scale with no depth-of-field scale, but infra-red index at 28 and 105mm. Hard stop at infinity. Focus ring is smooth, well-damped and direct-couple to lens barrel, making manual focus easy despite its short travel, which is extended in macro mode.

Maximum Reproduction Ratio 1:5.2; 1:2 (macro mode at 105mm), 1.2.7 (macro mode at 50mm)

Optional Accessories HB-18 Hood, CL-49 Hard Case or Pouch #62

Price Paid $149.00 (pre-owned). Original 1999 price: $290.00

RoHS Compliance None.

Sharpness Sharp at all apertures, but borders are softer at 105mm at large apertures.

Size 2.9" (D) x 3.2" (L)

Spherochromatism Not yet evaluated.

Sunstars Not yet evaluated.

Teleconverters Nikon TC-200, TC201 and TC-14A (manual focus). Tested with the Kenko Teleplus MC-7, it performed flawlessly on the D610 with full autofocus capability even in low light. The MC7 correctly reports its maximum aperture range as f/7.1-9 to f/45-57 (56mm-210mm respectively).

Variable Aperture Range
Full-Frame (FX)APS-C (DX)f-Stop Range
28mm42mmf/3.5-f/22
35mm52.5mmf/3.8-f/22
50mm75mmf/4-f/25
70mm105mmf/4.2-f/29
85mm127.5mmf/4.5-f/29
105mm157.5mmf/4.5-f/29

Versatility Good for: wide angle, portrait, close-up and macro. Not the best choice for sports photography, hand-held night photography or infrared.

Vibration Reduction (VR) None.

Vignetting Not yet evaluated.

Weight Approximately 17 ounces.


Build Quality ★★★★
Optical Quality ★★★★★
Value ★★★★★

The Bottom Line Ever since I first heard about the 28-70mm D by a fellow photographer in Starbucks, I was intrigued. I wanted to add an AF Zoom D lens to my collection for compatibility with both my film and digital bodies, and to be sort of “period” to my N80. A little research turned up this lens, which was every bit as good optically, but offered far more utility as a macro lens. The current 24-85mm D, while seemingly fast at f/2.8-4, is nowhere near as sharp as this lens. While not quite as wide as the 24mm, 28 is quite versatile and really handy on DX, where it’s considered “true normal” at 42mm.

Being well-suited for both FX and DX use, compatible with film bodies via its aperture ring and being such a great macro performer, this was the perfect choice for a D Zoom lens addition to my outfit. I feel as though I’ve finally gotten myself the macro lens I’ve been wanting for some time. In use, it’s really comfortable and well-balanced on the D610, and surprisingly easy to focus. And The two minor points that make this lens not absolutely perfect are the stiff aperture ring (typical of D lenses) and the rotating filter threads (typical of “kit” lenses). But neither of these are deal breakers.

Without autofocus motors, VR electronics and lead-free solder, D lenses seem to be more of an “investment” than G lenses, and provide a more traditional feel to shooting with a DSLR. And this particular D lens is one that I highly recommend.


Tuesday, April 29, 2014

First Impressions: AF Zoom-NIKKOR 28-105mm f/3.5-4.5 D

AF Zoom-NIKKOR 28-105mm f/3.5-4.5 D.
Once again, I am blown away by the excellent customer service at KEH Camera with my purchase of a previously-owned AF Zoom-NIKKOR 28-105mm f/3.5-4.5 D…

Review: AF-S Zoom NIKKOR 24-85mm f/3.5-4.5 G ED VR

AF-S NIKKOR 24-85mm f/3.5-4.5 G ED VR
This lens is basically an update to a previous G lens with the same zoom range and variable aperture. It adds VR, which increases its versatility greatly, allowing it to capture images under more challenging lighting conditions.

Although this lens is offered as a bundle with several full frame bodies, it’s anything but a “kit” lens. Having a slightly wider and longer range than an 18-55mm does on an APS-C body, it’s essentially the full-frame equivalent of that lens, but with a metal mount, rear gasket, bayonet hood, stationary filter ring and focusing scale. Tack on outstanding performance, and this quickly becomes a must have.

Because Nikon has shown restraint with regard to focal length range, this lens comes in at a price that gives it great value. Its extra speed at the long end set it apart from similar offerings. Some may say that the range of 24-85mm seems limiting, but I find it to be an ideal compromise between a very useful range, and a compact, easy to handle form factor.

It’s faster that the typical lens in its class, and its minimum aperture of f/4.5 at 85mm makes it a significant 2/3 stop faster. With a hard stop at 85mm it’s ideal for portraiture, where its nearly 4-stop VR advantage make it behave more like f/1.4. Unlike “kit” lenses, it has a metal mount, making it more durable, although it has the typical build quality of a non-professional G lens.

In the real world, this lens is very easy to live with. In room light, I’ve shot at 85mm with a low ISO at 1/6 sec. That’s four stops right there, and at times I’ve pushed it one more with surprising results. The combination of focal length range, speed and VR performance are in perfect balance. This lens simply does not try to do more than it can, and what it does do, it does well.

What’s missing from this lens is the active VR mode. I’ve never used it on my DX 16-85mm and it seems unlikely that with a maximum focal of 85mm that I would be using it for sports photography. For that I can simply use my 70-300mm f/4.5-5.6 which does have active VR mode. A depth of field scale and infrared index would also have been nice, but these omissions are typical of G lenses.

What’s included is the usual storage pouch, and a bayonet-mount tulip-style lens hood. As tulip hoods go, it’s a pretty extreme one with deeply cut sides, which actually helps a little when used with a polarizer. If you opt for the Hoya Screw-in Rubber Zoom Lens Hood, it will vignette in the range 24mm to about 35mm where the corners peak through a tiny bit. Not to worry though, since this lens has good resistance to ghosts and flaring, so a hood is not essential.


Aperture Ring None. Aperture is controlled through the command dial on the camera body.

Auto Focus Built-in Silent-Wave motor makes this lens compatible with professional, semi-professional and entry-level cameras. Average focus speed and very accurate.

Bokeh Like most zoom lenses which seek to achieve optimum sharpness, the bokeh is a compromise. For best results, shoot in close proximity to the subject at 85mm at f/4.5.

Close Focus 7.25" from the lens. Works well with close-up filters and short extension tubes.

Color Rendition Typical of most NIKKOR AF-S lenses.

Compatibility Works with Nikon Digital SLRs and AF film SLRs such as the F6, F100, F5, N80  and N75. On the N90s, N70 and F4 you won’t have VR, Aperture Priority or Manual exposure modes.

Construction 16 elements in 11 groups, including 1 ED glass element and 3 aspherical elements. Polycarbonate outer and inner barrel, metal mount, rear gasket.

Country of Origin China.

Coverage 135 film, FX and DX.

Diaphragm 7 curved blades.

Distortion Considerable, but corrected in-camera for JPEGS, and can be corrected easily during post-processing.

DX Performance When used on a DX camera this lens has a very usable range of 36-127.5mm, and is faster at the long end than its DX equivalent, the AF-S DX Zoom-NIKKOR 16-85mm f/3.5-5.6 G ED VR. When used on an FX camera in DX crop mode, its range is extended to 127.5mm, although at lower resolution.

Extension Tubes Tested with the Kenko Auto Extension Tube Set DG, it hunts and finds with the shortest tube, but rarely finds with the longest tube. Therefor use with autofocus in not entirely out of the quesiton. Manual focus should be fine, were VR will be preserved.

Falloff Visible only wide-open at 24mm, and corrected in many of the newer cameras.

Filter Thread Plastic, 72mm. Does not rotate with either zoom or focus rings. With more than one filter, very slight vignetting occurs at 24mm, which can be prevented by taking the Filter Leap of Faith. If you’re using this lens with Cokin filters, you won’t encounter vignetting at 24mm with the standard filter holder as long as you use it without a screw-in filter. Also, you can use one section of the modular hood, as long as it’s mounted as close to the lens as possible. If you use unusually thick filters, such as the P173 Varicolor Polarizer, you’ll get just a tiny bit of vignetting at 24mm, which is gone by 35mm.

Ghosts and Flares Very well controlled, making a lens hood largely unnecessary, except for protection or “coolness factor”.

Included Standard center-pinch front lens cap, LF-4 rear cap, HB-63 plastic tulip-style lens hood, CL-1118 pouch.

Lateral Color Fringes Virtually none at 24mm, and only very slight blue-yellow fringes at 50 and 85mm.

Macro About average performance for a standard zoom. Close focusing at 7.25" from the lens enables a reproduction ratio of 0.22x. Switching to DX Crop mode increases that to 0.33x.

Manual Focus Focus scale with no depth-of-field scale or infra-red index. No hard stop at infinity. Manual override at all times. Focus ring is smooth, has slight play making it a challenge to rock back and forth for precise focusing.

Maximum Reproduction Ratio 1:4.5 (0.22x)

RoHS Compliance 10 years.

Sharpness Always super-sharp in the center, and almost as sharp in the borders and corners at 50mm. At 24 and 85mm, the sides and corners are a little softer, becoming optimally sharp at f/11 (24mm) and f/5.6 (85mm).

Spherochromatism Virtually none.

Sunstars Soft, 14-pointed, becoming sharper with underexposure.

Teleconverters Tested with the Kenko MC7, there is perpetual hunting. Autofocus use not recommended, but should be fine for manual focus, where VR is preserved.

Variable Aperture Range
Full-Frame (FX)APS-C (DX)f-Stop Range
24mm36mmf/3.5-f/22
35mm36mmf/4.0-f/25
50mm75mmf/4.2-f/29
70mm105mmf/4.5-f/29
85mm127.5mmf/4.5-f/29

Versatility Good for: wide angle, portrait and close-up; macro with closeup lenses or extension tubes. Not the best choice for sports photography, hand-held night photography or infrared.

Vibration Reduction (VR) 4 stop improvement claimed. In the field, 3 stops are more common.

Vignetting More that one filter vignettes a small amount at 24mm. This lens is a good candidate for slim filters, or use of oversized filters with a step-up ring.


Build Quality ★★★★
Optical Quality ★★★★★
Value ★★★★★

The Bottom Line Purchasing this lens as a bundle with the Nikon D610 was a much better experience than if I had purchased my D90 with the plastic-mount 18-105mm. This lens is a huge improvement over previous offerings, having considerably better performance in the corners, a better build and the all-important VR. It is also quite compact and easy to keep with you. This is the lens I keep on my D610 at all times.

The range of 24-85mm was well chosen. The “hard stop” at 85mm give credibility to this as a portrait lens, where its faster f/4.5 maximum aperture performs similar to f/1.4 with VR for stationary subjects. In the field, if I need more reach I switch to DX crop mode at “L“ resolution, where it maxes out to 127.5mm.

I would highly recommend this lens to any first-time, full-frame Nikon owner, and also to those DX owners with a plan to purchase a full-frame camera in the future. For those who already own a full-frame Nikon, it’s definitely a worthwhile addition to your kit.


Monday, April 28, 2014

The Tale of the 18-55

My Honey, the Olympus gal, was in desperate need of a faster digital camera than her Nikon P5100, which I bought her as a Christmas gift in 2009. She needed something light and small; those were the requirements. And the Nikon D3100 fit the bill.

Wednesday, April 23, 2014

AF Zoom-NIKKOR 28-70mm f/3.5-4.5 D

AF Zoom-NIKKOR 28-70mm f/3.5-4.5 D. Another outstanding standard zoom.
A couple of years ago, I ran into a chap at Starbucks who was telling me about a great 28-70mm lens that he had used…

Monday, April 21, 2014

The Filter Leap of Faith

Fotodiox 49-77mm Step Up Ring Set
Photo courtesy Mike Hagen, outthereimages.com
Filters are necessary and expensive. How much so depends on what you plan on shooting, the quality you are looking to achieve, and how much free time you have. But, there is a way to minimize the expense…
